Stainless steel actuators are viable, long-term flow automation solutions to regulate the flow of metalworking fluids, compressed air, and industrial waste. These fluids bear different chemical and physical properties which impact valve and actuator performance and durability.
Metalworking fluids, such as cutting oils and coolants, can contain chemicals that may be corrosive or abrasive. Stainless steel actuators can withstand these harsh environments, ensuring smooth and precise regulation of fluid flow.
Compressed air is another common medium in industrial processes, and stainless steel actuators can effectively control its flow. The durability of stainless steel helps prevent wear and tear, ensuring long-term performance and minimizing maintenance requirements.
Industrial waste can be highly corrosive and contain aggressive substances. Stainless steel actuators provide excellent resistance to chemical attack, making them suitable for regulating the flow of such fluids.
Overall, stainless steel actuators offer a combination of strength, durability, and chemical resistance, making them a reliable choice for flow automation solutions in industrial settings.
Technical Parameter
XM STAINLESS STEEL PNEUMATIC ACTUATOR OUTPUT TORQUE TABLE
|
Model |
Input air pressure(unit:bar) |
|||||
|
3 |
4 |
5 |
6 |
7 |
8 |
|
|
Air pressure output torque(N.m) |
||||||
|
XM-DA45-SS |
7.2 |
9.6 |
12.0 |
14.4 |
16.8 |
19.2 |
|
XM-DA52-SS |
12.0 |
16.0 |
20.0 |
24.0 |
28.0 |
32.0 |
|
XM-DA63-SS |
21.7 |
28.9 |
36.0 |
43.4 |
50.6 |
57.8 |
|
XM-DA75-SS |
30.0 |
40.0 |
50.0 |
60.0 |
70.0 |
80.0 |
|
XM-DA83-SS |
46.8 |
62.4 |
78.0 |
93.6 |
109.2 |
124.8 |
|
XM-DA92-SS |
67.6 |
90.1 |
112.6 |
135.2 |
157.7 |
180.2 |
|
XM-DA105-SS |
97.7 |
130.3 |
162.9 |
195.5 |
228.0 |
260.6 |
|
XM-DA125-SS |
150.5 |
200.6 |
250.8 |
301.0 |
351.1 |
401.3 |
|
XM-DA140-SS |
260.7 |
347.6 |
433.8 |
521.4 |
608.3 |
695.2 |
|
XM-DA160-SS |
397.2 |
529.6 |
662.0 |
794.4 |
926.8 |
1059.2 |
|
XM-DA190-SS |
640.2 |
853.6 |
1067.0 |
1280.4 |
1493.8 |
1707.2 |
|
XM-DA210-SS |
798.0 |
1064.0 |
1330.0 |
1596.0 |
1862.0 |
2128.0 |
|
XM-DA240-SS |
1154.3 |
1539.0 |
1923.8 |
2308.5 |
2693.3 |
3078.0 |
|
XM-DA270-SS |
1755.0 |
2340.0 |
2924.0 |
3510.0 |
4095.0 |
4680.0 |
|
XM-DA300-SS |
2291.4 |
3055.2 |
3819.0 |
4582.8 |
5346.6 |
6110.4 |
|
XM-DA350-SS |
3426.0 |
4568.0 |
5710.0 |
6852.0 |
7994.0 |
9136.0 |
|
XM-DA400-SS |
4872.0 |
6496.0 |
8120.0 |
9744.0 |
11368.0 |
12992.0 |
Always focus on better quality Pneumatic Actuators, contact us!
NO suffer pneumatic actuator leakage problem, contact us!
Pneumatic Actuators with true output torque data in the catalogues, contact us! (We have torque measure machine by ourselves.)
